Play video

Black-Edition
4K Dash Cam, Auto Stop/Start Kit - Smart Parking Mode, Polarised Lens, 128GB SD-Card & Case

Regular price: £189.95
Regular price: ~~£299.95~~
Sale price: £189.95
Save {{ saved_amount }}: Save £110.00

Tax included. Shipping calculated at checkout.

The Black Edition camera package includes everything a driver needs to ensure coverage whether driving, stopped or parked. Instantly view the front camera high-quality footage you have captured on the dash cam's 3" full-colour LCD screen without any loss of resolution. Other features include HDR - High Dynamic Range reduces dark & light contrasts. 3-Axis G-Sensor that detects outside force, and GPS adds location data.

The Black Edition Pro package includes the Auto Stop/Start smart hardwire kit - assured protection for cars fitted with stop-start systems.

Key Features

Black Edition Dash Cam Features

3.0" Wide full-colour TFT LCD screen
4K HD Recording Resolution (3840 x 2160px @ 30fps)
3-Axis G-sensor built-in
GPS receiver built-in
F1.8 Bright Lens with 130°(diagonal) wide viewing angle
Polarised filter lens
Micro SDHC/SDXC card slot (8 ~ 256GB), 128GB card included
Rear camera Input / 2 channel recording front & back with supplied KCA-R200 rear view camera
WiFi Built-in for wireless LAN & smartphone app link
PC/Mac software & Smartphone (iOS & Android app)
Magnetic quick-release mount

Auto Stop/Start Hardwired Kit Features

Actives Smart Parking Mode
Provides permanent power feed

Specifications

Image Sensor

1/1.8 Colour CMOS Sensor

Viewing Angle (Diagonal / Horizontal / Vertical)

D: 130° / H: 129° / V: 72°

Lens (F-number)

F1.8 Bright Lens

Display

3.0" Full Colour TFT

Polarised Filter

Rear View Camera

Requires Optional KCA-R200

Recording Resolution | Frame Rate

4K Ultra HD 3840 x 2160px 8.3M Pixels (Dashcam Only) / Full HD 2560 x 1440px (Front/Rear Cams) | 30fps

Built-in On / Off (Default)

3-Axis G-Sensor / GPS

Yes / Yes, GPS Adds location, date & time to your videos)

Recording Mode

Loop / Manual / Event / Still Image / Parking (When using hard wire kit supplied)

Event Recording Time

1 (Default) / 3 Minutes

Parking Mode Recording Time

30 Seconds

Voice Recording (Mic & Speaker)

Yes (ON / OFF)

Recording Media | SD-Card Supplied

microSDXC / SDHC Card 8 GB ~ 256 GB, UHS Speed Class (U3) | 128 GB

File Format | Video / Audio / Picture Format

MOV | H.264 / Linear PCM / JPEG

Quick Release Magnetic Mount

Backup Battery

Built-in Super Capacitor

Desktop Software Windows & MAC | Wireless Smartphone Link App

KENWOOD Video Player | iOS & Android

Mounting Bracket

Suction-cup & Adhesive

Power

Hardwire Kit or Cigar Lighter Adaptor

Dimensions / Weight

106 x 50.5 x 40.5 mm / 108 g (Dash cam only)

HARDWIRE KIT

Input | Output

12 ~24VDC, 2A | 5VDC, 2A, Mini-USB

Smart Parking Mode

Yes, Activated when using Hardwire Kit supplied

Warranty Dashcam

1-Year Parts & Labour

Whats in the Box

Black Edition 4K Ultra HD dash cam
128GB Class 10, U3 SD-Card (Memory card)
Polarised filter lens
Suction-cup mounting bracket
Adhesive mounting bracket (2 adhesive pads)
Cigar lighter car charger adapter, 4m lead (12~24V DC). Required for power, if not using the supplied CA-DR1030 hardwire kit in this bundle
USB cable 110 cm
Cable clips x 4
Instruction manual
Quick set-up guide

Auto Stop/Start Hardwire Kit
3 Different sizes of fuse-holder for simple connection to most fuse boards
Click to view or download manual

NOTE: After installation please ensure you start your engine. Otherwise, your dash cam may remain in sleep mode (smart parking), due to battery conditions.

Installation Information

IMPORTANT NOTES: We recommend that you contact a Professional Installer for the installation of this kit.

After installation please ensure you start your engine. Otherwise your dash cam may remain in sleep mode, due to battery condition.

Warranty & Customer Support

Our products come with a manufacturer's 1-year parts & labour warranty from the date of supply.

We recommend contacting our Technical/Customer Relations Team for assistance if you encounter any issues during this period. You can contact them via our Support Portal: https://kenwoodsupport.co.uk/support-ticket/.

Our dedicated team is available from Monday to Friday, excluding bank holidays. They strive to respond to inquiries within 24 hours or sooner. Please check your junk/spam folder, as their replies may occasionally end there.

Thank you for choosing our products, and we're committed to providing excellent support for any concerns you may have.

DPD Shipping

Experience Convenient DPD Deliveries Right to Your Doorstep!

Life's busy, and we get it. That's why DPD's seamless shipping solution ensures your package gets to you hassle-free, even when you're not home. Here's how:

Effortless Delivery: DPD brings your package right to your door, so you don't have to worry about missing out.
No Worries for Absences: Can't be home to receive your delivery? No problem at all. DPD has you covered. DPD will send you an email on delivery day, giving you the power to choose a nearby shop for pickup.
Local Pickup Convenience: Select a convenient drop-off point in your area. It's as easy as a few clicks, and you can collect your package on schedule.
Track and Tailor: Stay in control with our user-friendly DPD app. Track your parcel in real time and make any necessary changes, all from the palm of your hand.

With DPD, shipping doesn't have to be a headache. Embrace the flexibility, designed to fit your lifestyle.

Black Edition - For Drivers On the Go, Stopped, or Parked

Instantly view the front camera high-quality footage you have captured on the dashcam's 3" full-colour LCD screen without any loss of resolution. Other features include HDR - High Dynamic Range reduces dark & light contrasts. 3-Axis G-Sensor that detects outside force, and GPS adds location data.

The Black Edition package includes the Auto Stop/Start smart hardwire kit - assured protection for cars fitted with stop-start systems.

Many cars built in the last decade will automatically shut off the engine when the car stops to save fuel and improve emissions performance. However, the voltage drop in the car’s electrical system can fool a dash cam into thinking the ignition has been switched off or the battery is going flat, so it will automatically cut out to preserve power.

This can happen multiple times in a journey, leaving the car unprotected by video if there is an incident while it is stationary. To prevent this, KENWOOD's Auto Stop/Start wiring kit includes a sensor that delays switching the camera off to help ensure the camera remains ‘on guard’ when the car is in traffic. The kit also works perfectly with hybrid and fully electric cars.

The hardwire kit also enables smart parking mode, where the camera will wake from standby if the vehicle is struck or disturbed and video footage is captured. KENWOOD’s sophisticated electronics will automatically monitor the car’s battery to ensure it always has sufficient power, turning itself off if the voltage drops below a certain level.

Unparalleled Clarity with 4K Ultra HD Recording

Don't miss a single detail on the road – capture every nuance with the Black Edition's remarkable 4K Ultra HD recording capability. It boasts a staggering resolution of 3840 x 2160 and 8.3 million pixels. This dash cam offers unprecedented clarity. With four times the resolution of Full HD, you'll never have to strain your eyes to decipher crucial elements like license plate details again.

Enhancing Visual Excellence: HDR Dash Cam Captures Optimal Recorded Imagery

Helping to produce the best possible recorded image with HDR

Most dash cams (DVR) have a fixed lens aperture designed for average ambient lighting conditions. Unfortunately, in the real world, ambient lighting is not always average. Rising and setting sun or emerging from a dark tunnel can result in over or underexposed footage, possibly losing vital information such as number plates. HDR technology is designed to combat this by clever post-image processing to help produce a constantly clear and correctly contrasted recording. This technology also improves night vision recordings during night journeys.

Smart parking mode for KENWOOD dash camera

Black Edition includes the Auto Stop/Start smart hardwire kit. Perfect for hybrid and fully electric cars

Many cars built in the last decade will automatically shut off the engine when the car stops to save fuel and improve emissions performance. KENWOOD's Auto Stop/Start wiring kit includes a sensor that delays switching the camera off to help ensure the camera remains ‘on guard’ when the car is in traffic. The kit also works perfectly with hybrid and fully electric cars.

The hardwire kit also enables smart parking mode, where the camera will wake from standby if the vehicle is struck or disturbed and video footage is captured. KENWOOD’s sophisticated electronics will automatically monitor the car’s battery to ensure it always has sufficient power, turning itself off if the voltage drops below a certain level.

polarised filter lens for kenwood dash cams

Polarised Filter Lens - Sunglasses for your dash cam

The polarised filter lens helps to Reduce Dashboard Reflections, Glare and Improve Contrast Performance. We are all used to wearing polarised sunglasses on sunny days. Polarised lenses are designed to reduce sun glare and reflections to help us see better. Dash cams can also use this technology to ensure precise contrasted recording results. Without this critical information, such as number plates could be obscured by windscreen reflections and sun glare etc.

Black Edition KENWOOD dash cam viewing angle

Giving you the best view

Designed to provide recordings of the view in front of the vehicle and ensure detail is not lost. We deliberately do not go for Ultra-Wide Viewing Angle as the trade-off is distortion, leading to significant data loss.

GPS gives the right location, so no worries if you don't know

The location, date and time of any incident are vital as they can prove exactly when and where it has occurred, removing the need to write down everything shortly after an upsetting event. Your vehicle speed will be recorded and shown on the video playback. GPS satellite information can often be more accurate than the vehicle's speedometer. GPS will automatically adjust the time recorded to the current time zone when travelling abroad.

3-Axis G-Sensor: Detects unusual impacts to your vehicle

The built-in 3-axis G-Sensor with adjustable sensitivity can detect unusual impacts to your vehicle and automatically stores the video footage, time, speed and location. This footage is then moved into a locked folder so it cannot be overwritten. The locked folder can be viewed at a later time via the desktop software or smartphone app. Stored G-Sensor data could be helpful to show how significant any impact was, to combat against fraudulent claims.

Loop / Manual Recording

For longer journeys, all of KENWOOD's dash cams can be set to "loop record". This means that even when the SD-card is full, the camera will continue to record, overwriting the earliest footage. In this mode should an incident occur, or the manual recording button is pressed, this data footage will still be stored and protected from over-writing so it can be played back at a later time.

Release Magnetic Mount

Experience the convenience of effortless detachment and swift installation with the revolutionary magnetic mount. KENWOOD's Black Edition makes it a breeze to remove the camera for safekeeping or seamlessly switch it between different vehicles. Simplify your life and elevate your dash cam usage with this intuitive and practical design.
