501-ProDriver-Bundle
Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case

Regular price
£269.95
Regular price
Sale price
£269.95
Save {{ saved_amount }}
Save £-269.95
Tax included. Shipping calculated at checkout.

Instantly view the front and rear high-quality footage you have captured on the DRV-A501W's 3.0" full-colour LCD screen without any loss of resolution. Other features include HDR - High Dynamic Range reduces dark & light contrasts. 3-Axis G-Sensor that detects outside force, and GPS adds location data.

When installed, the hardwire kit supplied adds Smart Parking Mode. Then, when your vehicle is parked, the Smart Parking Mode becomes active, shutting down everything except the G-Sensor to save power. If your car is then subjected to a physical impact. Your dashcam stores the footage leading up to and after the incident. If the G-sensor detects other impacts during this recording, it will extend the recording time by 30 seconds until there are no more vibrations. The dash cam will then return to sleep mode (Smart Parking Mode).

    BUNDLES

    Add 3-Year Warranty Protection

    +

    ADD TO CART - £289.94
    Key Features

    DRV-A501W Dash Cam Features

    • 3.0" Wide full-colour TFT LCD screen
    • 3-Axis G-sensor built-in
    • GPS receiver built-in
    • F1.6 Bright Lens with 126°(diagonal) wide viewing angle
    • Polarised filter lens
    • Quad HD Recording Resolution (2560 x 1440px @ 30fps)
    • Micro SDHC/SDXC card slot (8 ~ 256GB), 16GB card included
    • Rear camera Input / 2 channel recording front & back. Using the included KCA-R100 rear-view camera
    • WiFi Built-in for wireless LAN & smartphone app link
    • PC/Mac software & Smartphone (iOS & Android app)
    • Magnetic quick-release mount

    KCA-R100 Rear View Camera Features

    • Full HD Recording Resolution (1920 x 1080px @ 30fps)
    • 161° Diagonal field of view
    • Wide Dynamic Range (WDR) mode
    • 180° Adjustable lens angle
    • 1/2.8 CMOS sensor
    • F2.0 Fixed focus lens

    CA-DR1030 Hardwired Kit Features

    • Actives Smart Parking Mode
    • Provides permanent power feed
    Specifications

    Image Sensor

    1/2.8 Colour CMOS Sensor

    Viewing Angle (Diagonal / Horizontal / Vertical)

    D: 126° / H: 126° / V: 110°

    Lens (F-number)

    F1.6 Bright Lens

    Display

    3.0" Full Colour TFT

    Polarised Filter

    Yes

    Rear View Camera Addition

    Yes, KCA-R100 Supplied

    Recording Resolution | Frame Rate

    WQHD 2560x1440px 3.7M Pixels (Dashcam Only) / Full HD 1920x1080px (Front/Rear Cams) | 30fps

    HDR

    Built-in

    3-Axis G-Sensor / GPS

    Yes / Yes GPS Adds location, date & time to your videos)

    Recording Mode

    Loop / Manual / Event / Still Image / Parking (When using CA-DR1030 hard wire kit supplied)

    Event Recording Time

    1 / 3 / 5 Minutes

    Parking Mode Recording Time

    30 Seconds

    Voice Recording (Mic & Speaker)

    Yes (ON / OFF)

    Recording Media | SD-Card Supplied

    microSDXC / SDHC Card 8 GB ~ 256 GB, Class 10 | 32 GB Included

    File Format | Video / Audio / Picture Format

    MOV | H.264 / Linear PCM / JPEG

    Backup Battery

    Built-in Super Capacitor

    Desktop Software Windows / MAC

    KENWOOD Video Player

    Wireless Smartphone Link App

    iOS & Android

    Mounting Brackets

    Suction-cup & Adhesive

    Power

    Cigar Lighter Adaptor

    Dimensions / Weight

    106 x 50.5 x 40.5 mm / 102 g (Dash cam only)

    KCA-R100 REARVIEW CAMERA FEATURES

    |

    Image Sensor

    1/2.8 Colour CMOS Sensor

    Viewing Angle (Diagonal / Horizontal / Vertical)

    D: 161° / H: +/- 129° / V: +/- 66°

    Adjustable Lens Angle | Lens (F-number)

    180° | F2.0 Fixed Focus Lens

    Recording Resolution / Frame Rate

    Full HD (1920 x 1080px) 3.7M Pixels / 30fps

    WDR

    Wide Dynamic Range (WDR) mode

    Installation Positions

    Normal / Up-side Down

    Dimensions / Weight

    63 x 66 x 36 mm / 334 g (Rearview camera only)

    Installation Positions

    Normal / Up-side Down

    Dimensions | Weight

    63 x 66 x 36 mm / 334 g (Camera only)

    CA-DR1030 HARDWIRE KIT

    |

    Input | Output

    12 ~24VDC, 2A | 5VDC, 2A, Mini-USB

    Smart Parking Mode

    Yes, Activated when using Hardwire Kit CA-DR1030 supplied

    Warranty Dashcam & Rear Camera

    1-Year Parts & Labour

    Whats in the Box
    • DRV-A501W Dash Cam
    • 32 GB micro SD card (Memory card)
    • Polarised filter
    • Suction-cup mounting bracket
    • Adhesive mounting bracket (2 adhesive pads)
    • Cigar lighter car charger adapter, 4m lead (12~24V DC) required for power. Required for power, if not using the supplied CA-DR1030 hardwire kit in this bundle
    • USB cable 110 cm
    • Cable clips x 4
    • Instruction manual
    • Quick set-up guide

    • KCA-R100 Internal Rear View Window Camera
    • Connection cable 8 meters
    • Adhesive tape pad (2 adhesive pads)
    • Instruction manual

    • CA-DR1030 Hardwire Kit
    • 3 Different sizes of fuse-holder for simple connection to most fuse boards
    • Click to view or download manual

    NOTE: After installation please ensure you start your engine. Otherwise, your dashcam may remain in sleep mode (smart parking), due to battery conditions.

    Installation Information

    IMPORTANT NOTES: We recommend that you contact a Professional Installer for the installation of this kit.

    After installation please ensure you start your engine. Otherwise your dash cam may remain in sleep mode, due to battery condition.

    Optional Extras

    > 3-Year Extended Warranty - Our extended 3-year warranty gives you extra peace of mind. Protect your KENWOOD dash cam & rear view camera for a total of 3-years from the date of purchase.

    Warranty & Customer Support

    Our products come with a manufacturer's 1-year parts & labour warranty from the date of supply.

    We do offer an extended 3-year warranty on the DRV-A501W dash cam & KCA-R100 rear view camera. Please select this option with the dash cam bundle at the time of purchase.

    We recommend contacting our Technical/Customer Relations Team for assistance if you encounter any issues during this period. You can contact them via our Support Portal: https://kenwoodsupport.co.uk/support-ticket/.

    Our dedicated team is available from Monday to Friday, excluding bank holidays. They strive to respond to inquiries within 24 hours or sooner. Please check your junk/spam folder, as their replies may occasionally end there.

    Thank you for choosing our products, and we're committed to providing excellent support for any concerns you may have.

    DPD Shipping

    Experience Convenient DPD Deliveries Right to Your Doorstep!

    Life's busy, and we get it. That's why DPD's seamless shipping solution ensures your package gets to you hassle-free, even when you're not home. Here's how:

    • Effortless Delivery: DPD brings your package right to your door, so you don't have to worry about missing out.
    • No Worries for Absences: Can't be home to receive your delivery? No problem at all. DPD has you covered. DPD will send you an email on delivery day, giving you the power to choose a nearby shop for pickup.
    • Local Pickup Convenience: Select a convenient drop-off point in your area. It's as easy as a few clicks, and you can collect your package on schedule.
    • Track and Tailor: Stay in control with our user-friendly DPD app. Track your parcel in real time and make any necessary changes, all from the palm of your hand.

    With DPD, shipping doesn't have to be a headache. Embrace the flexibility, designed to fit your lifestyle.

    501 Pro Drive KENWOOD bundle Dash cam DRV-A501W, rear view camera, hardwire kit, sd-card, polarised filter
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case
    KENWOOD 501 Pro Dash Cam Bundle Video
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case
    501-ProDriver-Bundle Front & Rear Cameras, Smart Parking Mode, Polarised Lens, 32GB SD-Card, Case

    501 Pro Driver Bundle - The full package

    The DRV-A501W dash cam boasts a remarkable 1.8-fold increase in pixel count compared to Full HD, resulting in crisp and detailed imagery. It is equipped with a state-of-the-art 3.7 megapixel CMOS sensor, enabling it to flawlessly capture Wide Quad HD video content at 30 frames per second.

    The 180° rotational rear view camera lens gives you total flexibility and provides an optimum view from various rear window angles. Also, it features a wide-viewing angle lens with a horizontal angle of +/- 129°, a vertical +/- 66°, and a diagonal 161°. The recording range at the vehicle's rear expands in all directions to ensure nothing escapes the footage.

    When installed, the hardwire kit supplied adds Smart Parking Mode. Then, when your vehicle is parked, the Smart Parking Mode becomes active, shutting down everything except the G-Sensor to save power. If your car is then subjected to a physical impact. Your dashcam stores the footage leading up to and after the incident. If the G-sensor detects other impacts during this recording, it will extend the recording time by 30 seconds until there are no more vibrations. The dashcam will then return to sleep mode (Smart Parking Mode).

    Smart Parking Mode: Recording Incidents When You're Away

    Help protect your vehicle from hit and run drivers, with the installation of our hardwire kit, which actives the Smart Parking Mode in your dash cam. Once installed, this intelligent mode takes charge when your vehicle is parked and the ignition is turned off. By conserving power intelligently, it shuts down non-essential functions while keeping the vigilant G-Sensor active. Should your parked vehicle encounter a physical impact, our advanced dash cam system springs into action, capturing and securely storing the crucial footage. The technology doesn't stop there – if the G-Sensor detects subsequent impacts during the recording, the system extends its capture by an additional 30 seconds, ensuring no crucial detail goes unrecorded. After fulfilling its duty, the dash cam seamlessly returns to its sleep mode within the Smart Parking Mode, ready to safeguard your vehicle whenever you're away.

    front & rear dash camera KENWOOD 501 Pro Driver Bundle

    Front & rear view with the DRV-A501W dash cam & KCA-R100 rearview camera

    Instantly view the front and rear high-quality footage you have captured on the DRV-A501W's 3.0" full-colour LCD screen or by using the smartphone or PC/Mac app.

    The KCA-R100 rear camera has a 180° rotational lens giving you total flexibility and provides an optimum view from various rear window angles. This camera even works if you have a tinted rear windscreen.

    polarised filter lens for kenwood dash cams

    Polarised Filter

    This lens helps to Reduce Dashboard Reflections, Glare, and Improve Contrast Performance. We are all used to wearing polarised sunglasses on sunny days. Polarised lenses are designed to reduce sun glare and reflections to help us see better. Dash cams can also use this technology to ensure precise contrasted recording results. Without this critical information, such as number plates could be obscured by windscreen reflections and sun glare etc.

    Helping to produce the best possible recorded image with HDR

    Most dash cams (DVR) have a fixed lens aperture designed for average ambient lighting conditions. Unfortunately, in the real-world ambient lighting is not always average. Rising and setting sun or emerging from a dark tunnel can result in over or underexposed footage, possibly losing vital information such as number plates. HDR technology is designed to combat this by clever post-image processing to help produce a constantly clear and correctly contrasted recording. This technology also improves night vision recordings during night journeys.

    GPS gives the right location, so no worries if you don't know

    The location, date and time of any incident are vital as they can prove exactly when and where it has occurred, removing the need to write down everything shortly after an upsetting event. Your vehicle speed will be recorded and shown on the video playback. GPS satellite information can often be more accurate than the vehicle's speedometer. GPS will automatically adjust the time recorded to the current time zone when travelling abroad.

    3-Axis G-Sensor detects unusual impacts to your vehicle KENWOOD dash cams

    3-Axis G-Sensor: Detects unusual impacts to your vehicle

    The built-in 3-axis G-Sensor with adjustable sensitivity can detect unusual impacts to your vehicle and automatically stores the video footage, time, speed and location. This footage is then moved into a locked folder so it cannot be overwritten. The locked folder can be viewed at a later time via the desktop software or smartphone app. Stored G-Sensor data could be helpful to show how significant any impact was, to combat against fraudulent claims.

    Loop / Manual Recording KENWOOD dash cams

    Loop / Manual Recording

    For longer journeys, all of KENWOOD's dash cams can be set to "loop record". This means that even when the SD-card is full, the camera will continue to record, overwriting the earliest footage. In this mode should an incident occur, or the manual recording button is pressed, this data footage will still be stored and protected from over-writing so it can be played back at a later time.

    KENWOOD dash cameras magnet mount

    Quick Release Magnetic Mount

    No more connecting cables with the quick release magnetic mount. Unlike traditional mounts, which operate using a latching mechanism. The patent-designed magnetic mount lets you place and remove the dash cam easily and immediately with no cable to connect or disconnect.

    KENWOOD dash cam app

    Wireless Smartphone App

    The KENWOOD Dash Cam App from App Store (iOS) for iPhone or Google Play (Android™) for Android smartphone allows you to change the menu settings of your dash cam easily.

    Go into the video settings of the app, and you can change the resolution, video length, exposure, GPS, Speed unit (MPH/KPH), time & date stamp, license plate stamp, and switch parking mode sensor on/off. * (Smart Park Mode requires the CA-DR1030 hardwire kit to be installed). Also, browse through recorded videos and real-time live view from your smartphone.

    *Ensure that your iPhone / Android smartphone is linked via Wi-Fi with your dash cam to change dash cam settings, browse recorded videos, and real-time live view.

    polarised filter lens for kenwood dash cams

    Polarised Filter Lens

    This lens helps to Reduce Dashboard Reflections, Glare and Improve Contrast Performance. We are all used to wearing polarised sunglasses on sunny days. Polarised lenses are designed to reduce sun glare and reflections to help us see better. Dash cams can also use this technology to ensure precise contrasted recording results. Without this critical information, such as number plates could be obscured by windscreen reflections and sun glare etc.
